7520 Series

7520-48Y-8C

The following figure illustrates the components on the front panel of the 7520-48Y-8C.

Click to expand in new window
7520-48Y-8C front panel view
7520-48Y-8C front panel view
  1. 48 1/10/25 Gbps SFP28 ports
  2. 8 40/100 Gbps QSFP28 ports
  3. 1 RJ-45 management port for CPU and BMC network access
  4. 1 USB Type-A port
  5. 1 RJ-45 serial console port
  6. System LEDs

7520-48YE-8CE

The following figure illustrates the components on the front panel of the 7520-48YE-8CE.

Click to expand in new window
7520-48YE-8CE front panel view
7520-48YE-8CE front panel view
  1. 48 10/25 Gbps SFP28 MACsec-capable ports
  2. 8 40/100 Gbps QSFP28 MACsec-capable ports
  3. 1 RJ-45 management port for CPU and BMC network access
  4. 1 USB Type-A port
  5. 1 RJ-45 serial console port
  6. System LEDs

7520-48XT-6C

The following figure illustrates the components on the front panel of the 7520-48XT-6C.

Click to expand in new window
7520-48XT-6C front panel view
7520-48XT-6C front panel view
  1. 48 1G/10GBase-T ports
  2. 6 40/100 Gbps QSFP28 ports
  3. 1 RJ-45 management port for CPU and BMC network access
  4. 1 USB Type-A port
  5. 1 RJ-45 serial console port
  6. System LEDs

The back panel (not shown) includes dual redundant hot-swappable power supplies and six hot-swappable fan units.

The 7520 Series supports one internal IAH port, 1/s1, used by IAH virtual machines. For conceptual information see Extreme Integrated Application Hosting. For configuration instructions to use internal IAH ports, see Virtual Services Configuration using CLI and Virtual Services Configuration using EDM.
